| 型号 | 电压KV | 电缆规格mm2 | 电缆外型尺寸㎜ | 电缆弯曲半径㎜ | 电缆参考重量kg/m |
| YJGCFRP | 6 | 3×16+3×16/3 | 43.2 | 648 | 1.848 |
| YJGCFRP | 6 | 3×25+3×16/3 | 51 | 765 | 2.632 |
| YJGCFRP | 6 | 3×35+3×16/3 | 56 | 840 | 3.2239 |
| YJGCFRP | 6 | 3×50+3×16/3 | 62.1 | 931.5 | 4.122 |
| YJGCFRP | 6 | 3×70+3×16/3 | 66.6 | 999 | 4.9434 |
| YJGCFRP | 6 | 3×95+3×16/3 | 72 | 1080 | 6.006 |
| YJGCFRP | 6 | 4×16 | 49.5 | 742.5 | 2.5413 |
| YJGCFRP | 6 | 4×25 | 56.1 | 841.5 | 3.303 |
| YJGCFRP | 6 | 4×35 | 61.6 | 924 | 4.071 |
| YJGCFRP | 6 | 4×50 | 68.4 | 1026 | 5.215 |
| YJGCFRP | 6 | 4×70 | 73.4 | 1101 | 6.29 |
| YJGCFRP | 6 | 4×95 | 81 | 1215 | 7.833 |
| YJGCFRP | 6 | 3×16+1×10 | 48.3 | 724.5 | 2.485 |
| YJGCFRP | 6 | 3×25+1×10 | 55 | 825 | 3.236 |
| YJGCFRP | 6 | 3×35+1×16 | 60.2 | 903 | 3.957 |
| YJGCFRP | 6 | 3×50+1×25 | 67.1 | 1006.5 | 5.154 |
| YJGCFRP | 6 | 3×70+1×35 | 72 | 1080 | 6.176 |
| YJGCFRP | 6 | 3×95+1×35 | 79.8 | 1197 | 7.684 |
移动设备卷筒用10KV高压软电缆(圆)
| 型号 | 电压KV | 电缆规格mm2 | 电缆外型尺寸㎜ | 电缆弯曲半径㎜ | 电缆参考重量kg/m |
| YJGCFRP | 10 | 3×16+3×16/3 | 45.4 | 681 | 1.99 |
| YJGCFRP | 10 | 3×25+3×16/3 | 55.5 | 832.5 | 2.972 |
| YJGCFRP | 10 | 3×35+3×16/3 | 58.2 | 873 | 3.404 |
| YJGCFRP | 10 | 3×50+3×16/3 | 66.6 | 999 | 4.524 |
| YJGCFRP | 10 | 3×70+3×16/3 | 71.1 | 1066.5 | 5.369 |
| YJGCFRP | 10 | 3×95+3×16/3 | 75.1 | 1126.5 | 6.23 |
| YJGCFRP | 10 | 4×16 | 52 | 780 | 2.734 |
| YJGCFRP | 10 | 4×25 | 61.1 | 916.5 | 3.737 |
| YJGCFRP | 10 | 4×35 | 64.1 | 961.5 | 4.301 |
| YJGCFRP | 10 | 4×50 | 73.4 | 1101 | 5.73 |
| YJGCFRP | 10 | 4×70 | 78.4 | 1176 | 6.836 |
| YJGCFRP | 10 | 4×95 | 83.5 | 1252.5 | 8.126 |
| YJGCFRP | 10 | 3×16+1×10 | 51.1 | 766.5 | 2.567 |
| YJGCFRP | 10 | 3×25+1×10 | 59.2 | 888 | 3.551 |
| YJGCFRP | 10 | 3×35+1×16 | 63 | 945 | 4.138 |
| YJGCFRP | 10 | 3×50+1×25 | 72.8 | 1092 | 5.476 |
| YJGCFRP | 10 | 3×70+1×35 | 76.7 | 1150.5 | 6.619 |
| YJGCFRP | 10 | 3×95+1×35 | 82.6 | 1239 | 7.898 |
